·Small and compact

·Small size, easy to apply to small environment

·High response speed

·Fast and accurate feedback and transmission of signals in high-speed motion

·High precision

·Micron-level positioning accuracy and Repeatability (RMS), providing precise positioning function

·LED status indicator

·Different lights represent different states, more intuitive display encoder status, easy to adjust when assembling.

·No mechanical friction

·The reading head has no contact with the grating ruler and will not produce wear.

·Disassembled

·Reading head easy to assemble and disassemble, no complex assembly requirements

·Output type/communication mode: ABZ differential output/BISS high-speed protocol communication

·Supply voltage, consumption current: 5V(-5%/+ 10%),200 mA (no load)

·The fastest response speed: 1μm:5 m/s

·Allowable Environment Temperature: 0 ℃ to 65 ℃

·Magnetic grid type: linear

·Position accuracy: ± 10 μm/m(25°C)

·Repeatability (RMS): ± 1 μm/m(25 ℃)

·Detection of effective length: 50000mm

·Thermal expansion coefficient: 11±0.5 μm/m/℃

· communication type:BISS High Speed Protocol Communications

· Supply voltage, consumption current:5V ± 10%,200mA (no load)

·The fastest response speed: 1μm:5 m/s

·Allowable Environment Temperature: 0 ℃ to 65 ℃

·Magnetic grid type: linear

· Position accuracy:±5μm/m

· Repeatability (RMS):1-3μm/m(25℃)

· Check Out Effective Length:16m

·Thermal expansion coefficient: 11±0.5 μm/m/℃
