DPO70000SX Series High Performance Real-Time Oscilloscopes
- Outstanding signal fidelity and perfect signal-to-noise ratio
- Stable and precise multi-channel timing for the most accurate analysis capability
- Compact instrument package with flexible expansion and easy reconfiguration
Specifications
| Product Introduction
The DPO70000SX provides ultra-high bandwidth real-time signal acquisition and analysis with up to 70 GHz analog bandwidth. The patented Asynchronous Timing Interleaved (ATI) architecture provides the lowest noise and highest fidelity for real-time signal acquisition. Low-noise, high-fidelity signal acquisition is critical in ultra-high-bandwidth applications such as long-range coherent Optical Communication, 400G data communications, and wideband RF. The flagship DPO77002SX adopts ATI (asynchronous time series interleaving) structure, which realizes the real-time acquisition performance of 70 GHz and 200 GS/s(5 ps/sample point). The noise of this patented symmetrical structure itself is much better than that of traditional bandwidth intersection. weaving method. The DPO70000SX provides the lowest noise, highest fidelity, and maximum performance, supporting complex optical modulation analysis, Dither (RMS) and noise analysis for high-speed serial signaling and frequency, and Phase and modulation analysis for wideband RF signals.
| Product Advantages
|
·70 GHz bandwidth, industry low noise, high ENOB
· compact appearance, can be expanded, the instrument can be very close to the device under test
· UltraSync structure to ensure accurate data synchronization in multiple systems. Easy implementation of main/extended operations in the system
·200 GS/s sampling rate, 5 ps timing Resolution
· MultiView Zoom, up to 1G point record length, support quick browsing and advanced search
|
| Product Applications
|
· analysis of Coherent Optical Modulation
· scientific research and defense data acquisition and analysis
·100G/400G Data Communication System Debugging
|
· PCIe debug and conformance testing
· debugging and Conformance Testing of High-Speed Serial Communication
· PCIe, USB, Thunderbolt, HDMI, DisplayPort, and more
|
DPO70000SX Series
DPO70000SX Series Oscilloscopes provide the most accurate real-time performance for ultra-wide bandwidth applications.
Low noise, 70 GHz real-time signal capture function, using the patented ATI structure
● Compact 5 ¼ "(3U) instrument package for the most versatile multi-channel system
● Exact scalable performance with UltraSync multiple time-synchronized buses
● Highest trigger performance,>25 GHz edge trigger bandwidth, unique envelope trigger function
● 14.1 Gbps hardware serial trigger-ensures that the acquisition is triggered when the specified 8b10b, 64b66b or universal NRZ pattern occurs for the first time, isolating the pattern-related effects
● Error Detector-This function is implemented in the trigger system to provide a simple error measurement against a defined pattern file to determine that there are no missing bits
